DIMENSIONS
Length Overall:
|
151.1 ft.
|
/ 46.05 m
|
Length Design Load Waterline:
|
140.7 ft.
|
/ 42.89 m
|
Length Between Perpendiculars:
|
135.7 ft.
|
/ 41.36 m
|
Beam Molded Amidships:
|
40.0 ft.
|
/ 12.19 m
|
Depth Molded to Main Deck:
|
22.0 ft.
|
/ 6.71 m
|
Draft Design Waterline:
|
20.5 ft.
|
/ 6.20 m
|
Draft (Light):
|
13.5 ft.
|
/ 4.10 m
|
Draft (Maximum):
|
22.5 ft.
|
/ 6.20 m
|
Tonnage (Gross):
|
198
|
GRT
|
Tonnage (Net):
|
134
|
NRT
|
Tonnage (Displacement):
|
1,890
|
LT
|
Tonnage (Dead Weight):
|
1,032
|
LT
|
Tonnage (International Gross):
|
852
|
GT ITC
|
Tonnage (International Net):
|
255
|
NT ITC
|
CONSTRUCTION
All Steel
PROPULSION & STEERING
Main Engines:
|
(2) ALCO 16-251 F
6,480 bhp@1,000 rpm (Combined)
|
Propellers:
|
(2) Stainless Fixed Open 4-Blade
135 inch x 135 inch
|
Gears:
|
Lufkin RSQ 4222
5:6:1 Ratio
|
Rudders:
|
(2) Unbalanced
|
Steering Stations:
|
Pilothouse
Bridgewings and Aft Station
|
PERFORMANCE
Speed (Free Route):
|
15 knots
|
Speed (Cruising):
|
13 knots
|
Bollard Pull: (Uncertified)
|
70 tons
|
Fuel Use/Range (Towing):
|
245 gph / 41 days
|
Fuel Use/Range (Cruising):
|
184 gph / 55 days
|
AUXILIARY MACHINERY
Generators:
|
(2) 150 kw driven by GM 8v-71
|
Electrical Power:
|
440 volt
|
Bow Thruster:
|
(1) 300 hp
|
CAPACITIES
Fuel Oil:
|
242,320 USG / 779.1 MT
|
Lube Oil:
|
3,640 USG / 11.7 MT
|
Potable Water:
|
15,150 USG / 57.3 MT
|
Drill Water:
|
39,510 USG / 152.4 MT
|
ACCOMMODATIONS
Total Personnel Capacity:
|
15
|
Staterooms:
|
8
|
Galley Seating:
|
10
|
Air Conditioning/Heating:
|
Central AC
Heat strips
|
Cooler:
|
165 ft3 Walk-In and Reach-In
|
Freezer:
|
165 ft3 Walk-In and Reach-In
|
Sanitation:
|
Holding Tank
|
CATEGORY
SOLAS Category:
|
Cargo Ship
|
ISM Category:
|
Other Cargo Ship
|
CERTIFICATES
ISM-Safety Management Certificate (ISM-SMC):
|
|
International Ship Security Certificate (ISSC):
|
|
Alternative Security Plan:
|
USCG Approved
|
VRP/SOPEP
|
|
FCC
|
|
|
|
ELECTRONICS
Radars:
|
(2) Furuno
|
Radios (SSB):
|
(2) SEA 235
|
Radios (VHF):
|
(1) Standard Sailor
|
Gyro Compass:
|
(1) Sperry SR130
|
Navigation Aids:
|
(1) Loran C
|
Hailer/Talkback:
|
(1) Raytheon RAY 430
|
GPS:
|
(1) Garmin 210
(1) JRC DGPS
|
AIS:
|
(1) JHS-182
|
INMARSAT:
|
(1) Mini-M
|
TOWING/ANCHOR HANDLING
Tow Winch Type:
|
Double Drum
|
Tow Winch Model:
|
InterCon DD 250
Side-by-Side
|
Tow Winch Line Pull:
|
350,000 lbs. @ Stall
|
Tow Winch Capacity:
|
4,000 ft. of 2¼ inch
Each Drum
|
Tow Winch Wire Tugger Capacity:
|
(1) 6 ton
|
Capstain Type:
|
(1) Hydraulic Drive
|
Tow Pins:
|
(1) Set
Remotely Operated
|
Stern Roller:
|
(1) 9 ft. diameter
with 12 ft. Live Section
|
TUG’S MOORING
Windlass:
|
1¼ inch Single Wildcat
Single Cathead
|
Anchors:
|
(1) 2,500 lb. Danforth
|
Chain:
|
1,170 ft. of 1¼ inch
|
FIRE FIGHTING
On-Ship:
|
15 hp @ 200 gpm
|
Extinguishers:
|
Full Compliment
|
ROUTES
Coastwise & Registry
* Vessel grandfathered under U.S. Regulatory Tonnage
REGISTRATION
Flag:
|
USA
|
Home Port:
|
New York City, New York
|
Official Number:
|
578810
|
Hull Number:
|
496
|
Builder:
|
Haller Marine
|
Year Built:
|
1977
|
Year Reconditioned:
|
2005
|
Call Sign:
|
WCX9569
|
IMO Number:
|
7719624
|
CLASSIFICATION
American Bureau of Shipping
• A-1 Towing Service
• +AMS
• International Load Line
|
HEIGHTS
Wheelhouse Eye Level:
|
23 ft. @ 20 ft. Draft
|
Top of Mast:
|
69 ft. @ 20 ft. Draft
|
SPECIAL EQUIPMENT
Deck Crane:
|
(1) 3 ton
|
Rescue Boat:
|
(1) Inflatable
|
Welding Machine:
|
(1) 290 amp
|
|
