OFFICIAL NUMBER:
1280825
YEAR BUILT:
2017
BUILDER:
Donjon Shipbuilding & Repair
SPUDS
Two (2) 26-inch Spud Wells on Port Side
Two (2) 20-inch Spuds: 70-ft. x 1-inch Wall (Free-Fall System)
All welded steel construction, flat bottom, flat deck, raked bow and raked stern.
LIGHTSHIP WEIGHT (Est.):
284 Long Tons
CAPACITY
Max Capacity (at max recommended draft): 1,400 short tons
DRAFT
Light Draft: 1.9 ft.  / 0.58 m
Recommended Max Loaded Draft: 8.4 ft.  / 2.57 m
DIMENSIONS
Length: 120′ 0″
Breadth: 60′ 0″
Depth: 10′ 0″
Displacement: 950 Tons
Draft: 4′ 0″
