DIMENSIONS
Length Overall:
 85 ft.
 / 25.91 m
Length Design Load Waterline:
 81.3 ft.
 / 24.78 m
Beam Molded Amidships:
 28.0 ft.
 / 8.53 m
Depth Molded to Main Deck:
 11.5 ft.
 / 3.51 m
Tonnage (Gross):
 137
  GRT
Tonnage (Net):
 93
  NRT

CONSTRUCTION
All Steel

PROPULSION & STEERING
Main Engines:
 (2) EMD 12-645-E2 @ 1,500 bhp
Propellers:
 (2) Rolls Royce Stainless 4-Blade
78 in. x 62 in.
Gears:
 (2) Falk 1235
2:9:1 Ratio
Rudders:
 (2) Spade
Steering Stations:
 (4) Pilothouse & Aft Station

PERFORMANCE
Speed (Free Route):
 11.5 knots
Speed (Cruising):
 10 knots
Bollard Pull:
 26 short tons / 23.6 MT
Fuel Use/Range (Towing):
 125 gph
Fuel Use/Range (Cruising):
 60 gph

AUXILIARY MACHINERY
Generators:
 (2) 55-kw Detroit Inline 6-71
Electrical Power:
 60 Hz, 3 Phase

CAPACITIES
Fuel Oil:
 28,268 USG
Lube Oil:
 500 USG
Fresh Water:
 3,609 USG

ACCOMMODATIONS
Total Personnel Capacity:
 7
Staterooms:
 4
Galley Seating:
 5
Air Conditioning/Heating:
 Central Air/Steam Heat
Cooler:
 Reach-In
Freezer:
 Reach-In
Sanitation:
 MSD
ELECTRONICS
Radars:
 (1) Furuno
(1) Simrad
Radios (SSB):
 (1) Standard Horizon
Radios (VHF):
 (4) Icom
Navigation Aids:
 (1) Garmin Depth Sounder
Hailer/Talkback:
 (1) Raymarine
GPS:
 (1) Garmin

TOWING / ANCHOR HANDLING
Tow Winch Type:
 Single-Drum
Tow Winch Model:
 Marky 32 with Level Winder
Tow Winch Capacity:
 2,500 ft. of 1⅝ inch wire

TUG’S MOORING
Anchor:
 (1) 120 lb. Danforth

FIRE FIGHTING
On-Ship:
 (2) 7 hp @ 50 gpm
Extinguishers:
 Full Compliment

ROUTES
• Coastwise
• Great Lakes
• Registry

REGISTRATION
Flag:
 USA
Home Port:
 Albany, New York
Official Number:
 287149
Hull Number:
 791
Builder:
 American Marine Corp.
Year Built:
 1961
Call Sign:
 WDD8915

CLASSIFICATION
• United States Coast Guard
• Uninspected Towing Vessel Exam Certified

HEIGHTS
Wheelhouse Eye Level:
 31 ft.
Top of Mast:
 48 ft.

SPECIAL EQUIPMENT & AVIATION CERTIFICATION
Welding Machine:
 (1) 250 amp
